Especificaciones:
General
Device Interfaces 1 x 10/100/1000 Gigabit Ethernet WAN/LAN port, 1 x 10/100/1000 Gigabit Ethernet LAN ports, 1 x Mini-SIM/UICC Slot, 1 x Reset Button, 1 x WPS Button, 1 x Power Port
LED Power, Internet, 2.4 GHz, 5 GHz, LAN, Signal Strength
Antenna Type Two detachable 3G/4G antennas
Functionality
Frequency Support
LTE Bands: FDD:1/3/7/8/20(2100/1800/2600/900/800 MHz, TDD: 38 (2600 MHz), Carrier Aggregation
(CA) Support: 1+3/1+7/1+8/1+20/3+8/3+20/3+7/3+38/7+20/3+3/7+7/38+38
UMTS: 1/8 (2100/900 MHz)
GSM/GPRS: Quad-Bands (850/900/1800/1900 MHz)
Data Rates LTE Downlink: Up to 300 Mbps, LTE Uplink: Up to 100 Mbps / DC-HSPA Downlink: Up to 42 Mbps, DC-HSPA Uplink: Up to 5.72 Mbps
Wireless IEEE Standard IEEE 802.11n/ac
Wi-Fi Data Rate
Up to 1200 Mbps with 802.11ac + 802.11n dual mode
Up to 866 Mbps with 802.11ac clients
Up to 300 Mbps with 802.11n clients
WAN Interface Static IP, dynamic IP (DHCP client), PPTP, and L2TP.
Security Protocol 64/128-bit WEP (Wired Equivalent Privacy), WPA & WPA2 (Wi-Fi Protected Access)
Firewall Network Address Translation (NAT), URL Blocking, Stateful Packet Inspection (SPI), MAC Filtering
Software
Device Management Web UI
Physical
Size 132 x 126 x 44 mm
Weight 300 g
Operating Temperature 0 to 40 °C
Storage Temperature -10 to 70 °C
Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Certifications CE , RoHS
